| Customer review |
|
 |
|
| Display Type |
8" EMF CRT
4/3 Electromagnetically Focused Tube
|
| Ansi-Lumen |
Projector |
250 / 1250 Lumen |
Screen |
83 Lux (200 cm Screen width) |
| Contrast |
15000:1 full on/off |
-
|
| Black Level |
- |
- |
| Offset |
-
|
| Resolution |
- |
| Video Modes |
PAL, SECAM, NTSC, HDTV 720p, 1080i, 1080p, EDTV 480p, 576p |
| Application |
CRT Projection | Very narrow picture width and rooms with very little light. |
| Light Source |
Matsushita P16LXV CRT Röhre
|
|
| Light Life |
ca. 10000 - 20000 h. (je nach Anwendung) |
| Operating Costs |
-
|
The projection is too dark.
The screen width should be reduced.
|
|
 |
|
Lux: |
83 Lux |
|
Contrast: |
15000:1 |
|
Candela pro m²: |
27 cd/m² |
|
Foot-Lamberts: |
8 fL |
|
 |
|
|
| |
| • |
|
| Focus |
Manual |
| Zoom |
No Zoom |
| Objective |
F=1,12 High brightness F1,03 |
| Throw Ratio |
- |
| Audio |
Nein |
| Connections |
S-Video
5 x BNC RGBHC in
Fbas in
RS232C Din9 pin in |
| Ceiling Mounting |
Yes, is possible. |
| Power |
500W |
| Size WxHxD |
590 x 362 x 1076 mm (23,2"x14,3"x42,4") 229,81 L/dm³
|
| Operating Noise |
32dB |
|
| Weight |
67,00 kg / 147,71 lbs. |
| Keystone |
- |
| Illumination |
- |
| Frequenz |
H-sync: 30-110 kHz
V-sync: 37-240 Hz
Range max.: 120 MHz |
| Foot-Lamberts |
8 fL
/ max. 138 cm screen width |
| Candela m² |
27 cd/m² |
| Features |
 Full HD 1080P compatible
Freeze
Gamma correction
Remote control with backlight
|
|
- |
In Comparison
The Barco Cine 8 digital compared to others not current "CRT Projection" projectors. |
| Ansi-Lumen: |
|
47 |
Weight: |
|
86 |
| Contrast: |
|
100 |
dB: |
|
87 |
| Black level: |
|
1 |
Power cons.: |
|
64 |
| Picture Total Points: | 49 |
Projector Total Points: | 79 |
|
| Popularity Top 100 |
|
| Points: |
|
21 |
| Ranking: |
57 (From: 472) |
|
|
|
|
|
| Status |
2006 Discontinued (EOL) // Last update of the data: 2025-02-26
|
| Data |
 Product Sheet english
Product Sheet english HC
  |
