The equipment of the Sanyo PLC XF42 projector includes 9000 ANSI lumens, a contrast of 1100:1 with a XGA 1024 x 768 display. The manufacturer rates the durability of the included lamp at 2000 hours. Thanks to the combination of optical lens shift and digital keystone correction, the projected image's position can be adjusted very flexibly. Thanks to the interchangeable lens system, the device can be equipped with optional lenses to react flexibly to different room sizes. Exact values for specific rooms are provided by the Lens Calculator. Regarding projection size, the value of 9000 ANSI lumens allows for an image width of up to 826 cm in darkened environments. In rooms with ambient light, the image width should be correspondingly reduced to a maximum of 551 cm. This model dates back to 2007 and is no longer part of Sanyo's current product range. As an archive device, the projector remains highly relevant in our database.
Calculated brightness quality The screen width may also be larger. Perfect
Lux:
3000 Lux
Contrast:
1100:1
Candela pro m²:
956 cd/m²
Foot-Lamberts:
279 fL
75 cm
•
Focus
Powered
Zoom
Powered
Objective
Throw Ratio
optional
Audio
3W Stereo
Connections
1 x DVI-I mit HDCP
1 x Audio RCA x 2
Computer 2 / Video
5 x BNC / YUV
1 x Audio RCA x 2
1 x BNC Video/YC
1 x S-Video
1 x Audioaus. Eingang RCA x 2
1 x USB
Control Port x 2
RS232C
Ceiling Mounting
Yes, is possible.
Power
1500W
Size WxHxD
581 x 251 x 791 mm (22,9"x9,9"x31,1") 115,35 L/dm³
Operating Noise
46dB
Shift: 75 cm
Shift: 20 cm
Shift: 20 cm
Shift: 75 cm
Weight
37,50 kg / 82,67 lbs.
Keystone
Vert.: +/-40°
Illumination
90%
Frequenz
H-sync: 15-120 kHz V-sync: 50-120 Hz Range max.: 230 MHz
Lens shift Funktion maximal Kensington Slot Gamma correction 24/7 continuous operation capable Remote control with laser pointer und mouse control Optional LAN network compatible. Digital Zoom 3D-AUCC Intelligent sharpness optimisation Faroudja DCDi optionally available Adapts to all mains voltages.
Lens shift Funktion maximal
