According to Dell, the S510 model provides 3100 ANSI lumens, a contrast ratio of 8000:1 alongside a WXGA 1280 x 800 resolution. The manufacturer specifies a runtime of 3000 hours for this projector's lamp. Looking at practical performance, up to 566 cm can be illuminated with 3100 ANSI lumens in dark environments. Once daylight is in the room, the image should ideally be no wider than 377 cm. Regarding signal processing, the model is compatible with incoming 1080P content. As an additional feature, an integrated media player enables the direct playback of files without an external source device. For convenient remote monitoring and administration, the projector is equipped with a classic RJ45 network socket. Specifically for the educational or business sector, an interactive whiteboard function is also integrated. Equipped with a microphone jack and built-in speakers (10W), audio signals during presentations can be played back directly without an external audio system. This model dates back to 2015 and is no longer part of Dell's current product range. In our projector directory, the device still generates high interest.
Display Type
1 x 0,65" DC3 S540 DLP Chip WXGA 16/10 Ti Digital Light Processing Chip
Ansi-Lumen
Projector
3100
Screen
1240 Lux (200 cm Screen width)
Contrast
8000:1 full on/off
8000:1 full on/off
Black Level
0,3875 min. Lumen
0,155 min. Lumen
Offset
62,5% 16 cm over screen top edge →
SCREEN
+Projector
Resolution
WXGA 1280 x 800
1.024.000 Pixel UXGA 1600 x 1200 compressed
Video Modes
Pal, SECAM, NTSC, HDTV 720p, 1080i, 1080p EDTV 480p, 576p Media player formats: jpeg / JPEG
PtG2 (konvertiert von
ppt)*
jpeg / JPEG
ppt / pptx / doc / docx /
xls / xlsx / txt / pdf
Application
Whiteboard | Training and company presentations, as well as product presentations. Medium screen width or rooms with a little more ambient light, max. 200 lumens.
Calculated brightness quality The screen width may also be larger. Perfect
70 cm (no Zoom)
Lux:
1240 Lux
Contrast:
8000:1
Candela pro m²:
394 cd/m²
Foot-Lamberts:
115 fL
78 cm
•
Focus
Manual
Zoom
No Zoom
Objective
F=2,6
Throw Ratio
0,35:1
Audio
2 x 10W
Connections
HDMI 1.4a in
2 x D-sub 15pin in 1 x out
Cinch Video in
Cinch Stereo in
S-Video in
Mini Jack Audio in und out
USB Typ A,B in
RS232C Din 9 pin in
RJ45 in
Mikrofon in
12V Trigger out
Full HD 1080P compatible Integrated Mediaplayer Eco Mode Remote control with laser pointer Lan network compatible. Short-throw projector Whiteboard function Built-in flash memory: 2GB
Full HD 1080P compatible
